Technical Datasheet
Pool Mechanical Equipment
Doc. No
FOY-CH-FLT-0005-01
Rodas Horizontal Bobbin-Wound Filter Horizontal Filament-Wound Pool Filter · Technical Datasheet
Pool Mechanical EquipmentCH-FLT-0005-01
The Rodas Horizontal Filament-Wound Filter is a horizontally installed filament-wound pool filter for the filtration line of public pools. The body diameter ranges from Ø1050 to 1800 mm and the length from 1900 to 4000 mm. At filtration velocities of 20, 30 and 40 m³/h/m² it delivers flow rates of 46-216 m³/h. Each model is sold under a separate code in the 2.5 bar and 4 bar classes.
Technical Specifications
- Body Diameter
- 1050 mm / 1200 mm / 1400 mm / 1600 mm / 1800 mm
- Length
- 1900 mm / 2300 mm / 2500 mm / 2700 mm / 3000 mm / 3500 mm / 4000 mm
- Filtration Area
- 1.72 m² / 2.12 m² / 2.32 m² / 2.51 m² / 1.96 m² / 2.87 m² / 3.21 m² / 2.23 m² / 3.02 m² / 3.65 m² / 4.10 m² / 4.58 m² / 5.41 m² / 6.25 m²
- Filtration velocity
- 40 m³/h/m² / 30 m³/h/m² / 20 m³/h/m²
- Flow Rate
- 69 m³/h / 64 m³/h / 46 m³/h / 70 m³/h / 50 m³/h / 59 m³/h / 115 m³/h / 129 m³/h / 89 m³/h / 91 m³/h / 110 m³/h / 164 m³/h / 150 m³/h / 137 m³/h / 216 m³/h
- Connection
- Ø110 mm / Ø125 mm / Ø160 mm / Ø140 mm / Ø200 mm / Ø225 mm
- Max. Operating Pressure
- 2.5 bar / 4 bar
- Filter bed height
- 0.6 m / 0.6 - 1 m
- Body Material
- Isophthalic polyester and fibreglass (filament-wound)
- Type
- Horizontal filter
All figures are manufacturer data; they vary by model.
Compatibility and connections
- Layout
- Horizontal body
- Diameter and length
- Ø1050-1800 x 1900-4000 mm
- Filtration velocity
- 20, 30 or 40 m³/h/m²
- Pressure class
- 2.5 or 4 bar
