01Overview
Users and applications
The Jet Stream pump creates a current for swimming in place by feeding water to the counter-current nozzle on the pool wall. It is chosen for counter-current systems that need a high flow rate. On the stainless steel models, all parts in contact with water are AISI-316. Power ranges from 2 HP to 5.5 HP: the models in the stainless steel series deliver 1.5, 2.2, 3.3 and 4 kW.
Compatibility and connections
- Power supply
- 230 V single-phase or 400 V three-phase
- Motor power
- 1.5-4 kW
- Body
- AISI-316 or plastic
- Connected to
- Counter-current nozzle
02Technical Specifications7 models
SpecificationJet Stream Pool Counter-Current PumpCode CH-MEK-0109-01 - CH-MEK-0109-07
- Type
- Counter-current
- Rated Power (P2N)
- 1.5 kW / 2.2 kW / 3.3 kW / 4 kW / 2.6 kW
- Voltage
- 230 V / 400 V
- Body Material
- AISI-316 / Plastic
- Weight
- 21.0 kg / 22.6 kg / 22.5 kg / 32.6 kg / 27.0 kg / 30.5 kg
03Models & Prices7 model
| Model | Code | Rated Power (P2N) | Price |
|---|---|---|---|
| 2 HP (1.5 kW) MRecommended | CH-MEK-0109-01 | 1.5 kW | €1,470 + VAT |
| 3 HP (2.2 kW) M | CH-MEK-0109-02 | 2.2 kW | €1,522.50 + VAT |
| 3 HP (2.2 kW) T | CH-MEK-0109-03 | 2.2 kW | €1,470 + VAT |
| 4.5 HP (3.3 kW) T | CH-MEK-0109-04 | 3.3 kW | €1,942.50 + VAT |
| 5.5 HP (4 kW) T | CH-MEK-0109-05 | 4 kW | €2,257.50 + VAT |
| 2 HP (1.5 kW) M, plastic | CH-MEK-0109-06 | 1.5 kW | €1,575 + VAT |
| 3.5 HP (2.6 kW) T, plastic | CH-MEK-0109-07 | 2.6 kW | €1,627.50 + VAT |
Prices are indicative; contact us for a current quote.
